Shilpin Vajra
Specifications
Features
Applications
Working Table Size (mm)
440 x 500
T-Slots
Number : 5
Center Distance : 90 mm Size : M8
Machining Area (X x Y x Z) (mm)
410 x 410 x 210
X x Y x Z Axis Travel (mm)
420 x 420 x 210
Distance of Spindle Bottom from table (mm)
56
Accuracy (With Pitch-compensation) (X x Y x Z) (mm)
Positional Accuracy:<0.010
Repeatability:0.005
Flatness Error of Working Table (mm)
< 0.03
Media Height (mm)
265
Gantry Width(mm)
480
Max. Load Weight (kg)
100
Pressure Deformation of Working Table
< 0.02 (300 kg)
Spindle Power (kW)
2.2
Spindle Rotate Speed (RPM)
24000
Tool Collet
ER16
Max. Tool Size (mm)
8
Max. Feed Rate (m/min)
6
Max. Feed Rate (m/min)
4
Total Power (kW)
4.0
Drive System
Digital AC Servo drives (Panasonic)
Control System
Syntec
Programming
ISO G-Code
Power Supply
220 V/ 50 Hz
Net Weight (kg)
900-1000
Machine Size (mm)
1300 x 960 x 1400
